Ekhwesi: Customer User Interface Unit

Traditionally split meters have required hard wiring between the metering device and user interface keypad. Now, with Ekhwesi's wireless user interface unit (wUIU(09), radio frequency is used between the devices, making installation simpler, better and faster. In addition, through the use of RF (radio frequency), users are assured of a working solution with no interference, that can operate comfortably up to 100 metres. An added benefit is that the wUIU(09) is fully compatible with Ekhwesi's extensive range of split meters.

The split configuration of the wBEC62 range of three phase meters, means that the metering device is installed outside the consumer's premesis, whilst the user interface keypad is installed within the home. This provides increased security, whilst ensuring consumer convenience. The new, No Power Tamper (Optional Advanced Tamper) detection capabilities detect tamper even in the absence of an incoming supply.

Main Features

• Alkaline batteries
• Quick and easy to install and use
• Reduced installation costs
• Tactile keypad with audible feedback
• Operates on open (ISM) band
• Maximum Effective Radiated Power (ERP) of 10mW

Specifications (PLC):

Description	Value
Customer displayed information	Status of consumer's AC supply Available credit Low credit warning Token accept / reject Previously entered STS tokens (meter dependant) Meter status register Range dependent on environment and installation
Electrical ratings Battery size (Alkaline) No. of batteries required Battery voltage Operating voltage range Typical battery life	AA 2 1.5V 1.8V to 3V 3 years
Displays	Number of digits: 7 major / 2 minor Character height: 15mm / 7mm Type: Liquid crystal display Viewing area: 53mm x 30mm Enunciators: 6 icons and 10 segment bar graph
Keypad	Columns x rows: 3 x 4 Key press feedback: tactile / silicon rubber keys Accessibility: visually impaired friendly
Audible feedback	Key presses Token acceptance / rejection Low credit warning
ICASA approval	TA-2009/565
Standards	IEC 61000-4-2 IEC 61000-4-3 IEC 61000-4-4 IEC 61000-4-5 IEC 60950-1 CISPR22 Class B
Packaging Units per carton Packed box dimensions Weight	10 305mmx90mmx85mm 0.500kg packed weight (500g)

Overall Dimension

Standard Definition Short Codes

Code	Description
#000#	Dispenser test (STSO)
#001#	Load switch test (STS1)
#002#	Display test (STS2)
#003#	Input test device (STS6)
#004#	Accumulated energy consumed - MTTD (STS3)
#005#	Key revision and key type (STS4)
#006#	Tariff index (STS5)
#007#	Maximum power limit (STS7)
#008#	Tamper status (STS8)
#009#	Available credit
#010#	Phase unbalance (STS11)
#011# - #029#	STS reserved

Meter Operational Short Codes

Code	Description
#200#	Value of last credit token entered
#201#	ID of last credit token entered
#202#	Value of 2nd last credit token entered
#203#	ID of 2nd last credit token entered
#204#	Value of 3rd last credit token entered
#205#	ID of 3nd last credit token entered
#206#	Value of 4th last credit token entered
#207#	ID of 4th last credit token entered
#208#	Value of 5th last credit token entered
#209#	ID of 5th last credit token entered
#210# - #248#	Not used: value of credit token entered (6th - 25th tokens)
#211# - #249#	Not used: value of credit token entered (6th - 25th tokens)
#251#	Most recent token (Class, subclass, 20 digits, value)
#252#	2nd most recent token (Class, subclass, 20 digits, value)
#253#	3rd most recent token (Class, subclass, 20 digits, value)
#254#	4th most recent token (Class, subclass, 20 digits, value)
#255#	5th most recent token (Class, subclass, 20 digits, value)
#256#	6th most recent token (Class, subclass, 20 digits, value)
#257#	7th most recent token (Class, subclass, 20 digits, value)
#258#	8th most recent token (Class, subclass, 20 digits, value)
#259#	9th most recent token (Class, subclass, 20 digits, value)
#260#	10th most recent token (Class, subclass, 20 digits, value)
#261# - #270#	Not used
#271#	Estimated average daily and 30 day consumption
#272#	Last hour, 24 hour and 30 day consumption
#273#	Number of supply interruptions
#274#	Number of tamper detections
#275#	Lost communications counter
#276#	Eeprom memory data dump
#277#	Active load restriction duration and value
#278# - #299#	Not used

Manual Configuration Short Codes

Code	Description
#050#	Instantaneous power (STS9)
#051#	GPS coordinates
#052# - #069#	STS reserved
#070#	Power consumption per phase
#071#	Current consumption per phase
#072#	Average voltage per phase
#073#	Reason for last disconnect
#074#	Time remaining till zero credit
#075#	RF signal strenth
#076#	User total consumption to date
#077#	Total user credit entered
#078#	STS token result
#079#	Manual reconnect
#080#	UIU reset
#081#	Display UIU refresh interval
#082#	Meter tamper switch status
#083#	Not used
#084#	Last post paid / prepaid tenancy change MTTD register
#085#	Manual disconnect
#086#	Reactive power and power factor
#087#	Display consumption counter
#088#	Currently active load limit value
#089# - #099#	Not used

---

---

---

---
